NAD C338

A great entry-level amplifier with built in DAC that performs above its modest price point

In recent years, NAD has moved away from the old-fashioned linear power supplies and Class AB output stages that waste energy, and have instead developed even better performing circuits based on switch mode power supplies and Class D output stages. Once thought to be inferior to traditional topologies, NAD???s advanced work in this area has created some of the best performing amplifiers regardless of basic design principle. These new designs are very linear over a wide bandwidth and provide consistent performance into all speaker loads, providing a dramatic advance over previous models.

Furthermore, the power supply is capable of 160 watts continuously and over 300 watts instantaneously to allow for short-term musical transients. It can operate with any AC mains voltage from 100 to 240 volts and provides pure DC power to all the various stages of the C 338. This highly efficient supply also provides near perfect regulation of voltage across a wide range of conditions and provides a solid noise-free foundation for the amplifying stages.

Using a customized version of the proven Hypex UcD output stage, the NAD C338 allows for massive power with nearly unmeasurable distortion and noise in the audible range. Every detail of this amplifier has been carefully designed and perfectly executed to deliver every last drop of performance.

AMPLIFIER SPECS        NAD C338
Type Integrated
Number of channels 2
Frequency Response 20Hz-65kHz
Tone controls? Yes
Max power output into 8 Ohms  50W (at rated THD, 20-20kHz, both channels driven)
BluOS Ready? No

INPUTS:
Analogue RCA input Yes, 2
Optical digital input Yes, 2
Coaxial digital input Yes, 2
Bluetooth input? No

WiFi streaming? Wi-Fi enabled with network streaming of music services, internet radio, and support for Google Cast and UPnP
Dedicated turntable input? Yes, MM Phono input
USB connection? No
XLR inputs? No

OUTPUTS:
Analogue RCA Output No
Headphone output? No
XLR outputs?  No
Subwoofer output?  Yes
Bluetooth output?   Yes

GENERAL:
Remote control? Yes
Control App? Yes
Finish Graphite
Product dimensions (mm) (D) 302 x (W) 435 x (H) 71mm
Weight  TBC

GREEN SPECS:
Auto Power Off?  Yes
Standby Consumption (W) 0.5W
