ELAC DS-A101-G

The Discovery Series DS-A101 Wireless Integrated Amplifier


80-Watt-per-channel wireless control amp with DSP
The versatile and powerful Discovery Series DS-A101-G Wireless Integrated Amplifier is also the perfect complement to the Discovery Music Server. Together, they open up an unlimited vista of music where wireless convenience meets state-of-the-art sound. ELAC???s innovative smartphone application provides the tools for system setup, including sophisticated DSP, optimizing your subwoofer???s crossover frequency and room EQ.
This is one versatile integrated amplifier, with outstanding performance and feature-rich control flexibility. Once you experience the Discovery???especially with the new Debut or Uni-Fi loudspeakers???your world of sound just might be altered forever. Discovery does it all, at an affordable price.

Product Specifications
Amplifier: BASH Digital Fidelity Tracking Amplifier
Power output Continuous:
2 x 80 Watts 2 channels driven into 4 ohms @ 1kHz
2 x 40 Watts 2 channels driven into 8 ohms @ 1kHz
2 x 70 Watts 2 channels driven into 2 ohms @ 1kHz
Power output burst (CEA 2010*):
120 Watts 1 channel driven into 4 ohms @ 1kHz
65 Watts 1 channel driven into 8 ohms @ 1kHz
170 Watts 1 channel driven into 2 ohms @ 1kHz
Power and THD+N, 1kHz:
4 ohms 70 Watts @ .07%
8 ohms 40 Watts @ .03%
Signal-to-Noise Ratio: (Full Power Digital input): 101dB
Broadband Frequency Response: 20Hz to 40kHz +/- 1.8dB
Analog inputs: 2
Digital inputs: 2 total; 1 optical / 1 coaxial (192kHz 24-bit)
Ethernet Input: 1
Wi-Fi: Yes
Subwoofer Output: 1
Pre-Amp Outputs: 1 (L/R)
Bluetooth audio: Yes
Audio Decoding: Dolby Digital
Streaming Services: Discovery, Roon Ready, Spotify Connect, AirPlay, Bluetooth, DLNA
Display: OEL
App Control: Yes,  iOS and Android control app. A Bluetooth 4.0 low-energy Android or iOS device is required to use this application.
Room Correction: ABC (Auto Blend & Calibrate)
All specifications subject to change.
Power Consumption:
Power Off 120Vac: .86W
Auto-Off 120Vac: 5.45W
