QUAD VENA

Second-hand, in mint condition, without scratches. Supplied with its original package.

The Vena II is a versatile amplifier that delivers high-fidelity sound in a simple and affordable way, bringing audio quality to the highest levels for a variety of modern music sources, from vinyl and CDs to digital streaming and high-resolution files. With improvements over its predecessor, it is an ideal choice for those seeking a high-quality audio experience without complications.

Aesthetic and Functional Design
The Vena II stands out for its simple yet elegant design, typical of traditional hi-fi amplifiers. The front-mounted controls simplify operation while maintaining cutting-edge technical specifications.

Technology and Performance
The Class AB power amplifier is the heart of the Vena II. It features a new 200 VA toroidal transformer and a reservoir capacity of 2x15000uF (30000uF total), ensuring precise control of the music while maintaining excellent dynamic range. The Vena II is designed to handle even the most demanding audio sources with ease, adapting to a wide range of playback devices.

Phono Stage and Connections
A highly appreciated addition for vinyl enthusiasts is the phono stage for moving magnet cartridges, featuring a high-quality JFET circuit with low noise and precise RIAA equalization. Additionally, the Vena II offers a wide array of wired connections for total flexibility: asynchronous USB digital inputs, three S/PDIF ports (coaxial and optical), optical and coaxial digital outputs, and three RCA stereo inputs, including one MM phono input for turntables.

Streaming and Usability
For a modern listening experience, the Vena II also includes wireless Bluetooth streaming, with support for the aptX codec, enabling easy pairing with smartphones, tablets, PCs, and Macs. The streaming technology is designed to provide an optimal balance between quality and convenience, making the amplifier perfect for contemporary musical needs.

Headphone Amplifier
The Vena II also caters to headphone users. Unlike the previous model, which used the main output stage for headphones, the Vena II incorporates a dedicated headphone amplifier with current feedback circuits. This ensures more dynamic, detailed, and immersive performance, enhancing the audio experience with any type of headphones.

Compactness and Placement
With a smaller footprint compared to other amplifiers in its class, the Vena II fits easily into a variety of environments, making it an ideal choice for those with limited space.

Technical Specifications:

• Integrated Class AB amplifier with built-in DAC and Bluetooth 3.0 aptX connection
• Power: 45 watts per channel at 8 ohms
• DAC: 24 bit / 192 kHz, Crystal CS4398
• Analog Inputs: 2 L/R single-ended RCA inputs
• Digital Inputs:
  • 1x USB
  • 1x coaxial S/PDIF RCA
  • 2x optical Toslink
  • 1x iPhone/iPad/iPod (USB type A port)
• Headphone Output: 6.3mm jack (selectable output level, up to 3.5 V)
• Pre-out: Maximum level 2.3 V
• Digital Outputs: Coaxial S/PDIF RCA and optical Toslink
• Frequency Response: 20 Hz – 30 kHz
• Total Harmonic Distortion (THD): < 0.009% at 10 watts / 1 kHz
• Signal-to-Noise Ratio (S/N ratio): > 108 dB at 45 watts
• Input Sensitivity: 450 mV (analog RCA)
• Dimensions: 313 x 93.5 x 302 mm
• Weight: 6.1 kg
