ORTOFON QUINTET RED

Fonorivelatori Bobina Mobile Bassa Uscita Serie Quintet
Stilo ellittico, bobina in rame.


Peso 9gr.
Corpo in lega ABS/Alluminio di colore rosso
Impedenza di carico consigliata >20 ohm
Peso di lettura consigliato 2,3gr.
Tensione di uscita 0,5mV

Caratteristiche tecniche complete

Output voltage at 1 kHz 5 cm/sec 0.5 mV
Channel balance < 1.5 dB
Channel separation at 1 kHz > 21 dB
Channel separation at 15 kHz > 14 dB
Frequency range at -3 dB 20 - 25.000Hz
Frequency response 20-20.000 Hz +/-2.5 dB
Tracking ability at 315 Hz at recommended tracking force *) 65 ?m
Compliance, dynamic, lateral 15 ?m/mN
Stylus type Elliptical
Stylus tip radius r/R 8/18 ?m
Tracking force range 2.1-2.5 g (21-25 mN) Quintet SideRed02
Tracking force recommended 2.3 g (23 mN)
Tracking angle 20º
Internal impedance, DC resistance 7 Ohm
Recommended load impedance >20 Ohm
Cartridge body material ABS/Aluminium
Coil wire material Copper
Cartridge colour Red
Cartridge weight 9 g
