EMT HSD 006

Testina


The HSD 006 features our traditional stereo moving-coil generator, which has proven itself over decades in broadcast studios all over the world. The new body design makes it possible to bring professional EMT technology to your personal hi-fi system, letting you enjoy the intoxicating musicality of this outstanding transducer.

Specifiche tecniche
Diamond: SFL
Cantilever: Aluminium
Transducer: MC stereo
Magnet: AINiCo, nickel-plated
Body: Aluminium, red anodized
Connection: 1/2"-4 pin
Vertical tracking Angle: 23°
Weight: 12g
Tracking force: 2,4 g
Output voltage: 1.05mV @5cm/s
Compliance: 12um/mN
Frequency response +/- 2 dB: 20-25.000 Hz 40-12500 Hz
Impedance: 2x 24 Ohm
Recommended load: 200-300 Ohm

Nomenclature
HSD: Hi-fi Stereo Diamond
006:Stylus tip radius in microns
SFL: Super Fine Line diamond shape
