VITUS SIA-030

Amplificatore integrato

Creating a product intended to be a model up from a much coveted and multi-award-winning icon, the SIA-025 in this instance, is no easy task. A casual exploration of the sheer number of accompanying 5-star reviews and awards from all over the world tells you all you need to know. The SIA-025 has become a glittering halo in the world of integrated amplifiers so the SIA-030 always had its work cut out in no uncertain terms.
This stratospheric performance expectation, combined with the goal of keeping the chassis as "small" as possible, made the design phase extremely demanding and challenging, pushing our team to the absolute maximum. Thinking way outside of the box and endlessly obsessing over every possible micro detail of the design was required to achieve the almost impossible.
The technology inside the SIA-030 reuses the regulated power supply for the output stage of the Masterpiece MP-M201, combined with new technology for the lower voltage stages. The regulator module can easily be upgraded for future designs and likewise for the gain-stages in both the preamplifier and power-amplifier section. The newly developed volume control is now regulated only 0.5dB pr. step throughout the entire volume control. The total gain available is 18dB, which combined with the input sensitivity selector and high resolution of the volume control, offers full versatility for any sources and loads.
Two optional modules are offered. Firstly, a full DAC/Streamer module already known from the Rl- 101 / RD-101 but further optimized and enhanced for a performance befitting of the SIA-030. Secondly, a full phonostage with two non-balanced inputs, mm/mc support and individual load and gain settings. Fully equipped, the SIA-030 will be all you will need for a minimalistic 'uber' performing system with matching speakers and cables.


Specifications
Product Type: Balanced Integrated Amplifier
Volume: Relay controled fixed resistor network
Resolution: -91.5dB to -75dB = 1.5dB steps / -75db to +18dB = 1dB steps
Inputs: 3 x XLR analog / 2 x RCA analog
Input Impedance :10 K?
Input Sensitivity: 2/4/8 V RMS
Outputs: 1 x set balanced speaker out / 1 x pre out (XLR)
Output Power : 2 x 30w rms Class A (8?) / 2 x 200w rms Class AB (8?) – switchable
Remote Control: VA RC-010 remote included
Power Cable: Standard PC powercord included - options available on request at extra price
Dimensions: 265 (H) x 435 (W) x 478 (D) mm (Connectors not included)
Weight: 55 Kg
Options: RI-100 DAC - Extended RI-101 DAC with streamer (Expected available in 3Q18)
