KLIPSCH R-800F

Next-gen Reference Series. Floor-standing, 2-way bass reflex speaker, with advanced design and construction, featuring internal bracing, inert and free from coloration.

The updated horn design, with larger external dimensions, offers greater power and excitement both in music and movies. A larger horn means better control of directionality across a wider frequency range, resulting in a more precise soundstage.

Aluminum Tweeter with Linear Travel Suspension (LTS)

A distinctive feature of Klipsch speakers, the exclusive 1" LTS tweeter with Kapton suspension minimizes distortion, delivering more detailed performance. Aluminum, an extremely light and rigid material, is used in the tweeter assembly to maximize efficiency.

Thermoformed Crystalline Polymer Woofer with Copper Finish

Thanks to the technology derived from the renowned Klipsch Reference Premiere series, the 4" TCP woofers are designed with a more pronounced cone angle for a smoother response, greater precision, and improved transparency.

High-Quality Cabinet Design and Appearance

The speakers feature hidden mounts, an edge-to-edge horn, and low-profile magnetic grilles, giving them a sleek and modern look. The MDF cabinets, with scratch-resistant wood veneers, integrate harmoniously into home decor.

Technical Specifications:

• 1" LTS (Linear Travel Suspension) tweeter with aluminum diaphragm and Kapton suspension, with a rear-vented enclosure and next-gen Tractrix Horn 90° x 90° loading system, characterized by a wider horn extending to the sides of the cabinet, capable of reconstructing a wider soundstage and a more precise image.

• 2 x 8" (20 cm) woofers with TCP (Thermoformed Crystalline Polymer) copper filament membrane, redesigned to ensure a more linear and transparent response.

• Tractrix Port reflex port with rear panel exit.

• New set of additional connectors for optional Atmos Enabled channel connection, hidden by a removable plate and placed at the top of the rear panel.

• Nominal impedance: 8 ohms.

• Sensitivity: 98 dB (2.83 V / 1 m).

• Frequency response: 34 Hz - 21 kHz (+/- 3 dB).

• Crossover frequency: 1400 Hz.

• Power handling: 600 W peak / 150 W RMS.

• Disconnection feet made by injection molding.

• Magnetic grille with front panel mounts hidden under the finish.

• Black finish with wood veneers and a scratch-resistant satin-painted front panel.

• Dimensions (W x H x D): 277 x 1093 x 443 mm.

• Weight: 24.5 kg.
