KLIPSCH R-40M

Next-Gen Reference Series. 2-way bass reflex support speaker, with advanced design and construction, featuring internal reinforcements, inert and free of coloration.

The updated horn design, with enlarged outer dimensions, delivers more power and emotion to both music and movies. A larger horn means better directivity control across a broader frequency range, resulting in a more precise soundstage.

Linear Travel Suspension (LTS) Aluminum Tweeter

A hallmark of Klipsch speakers, the exclusive 1" LTS with Kapton Suspension tweeter minimizes distortion for more detailed performances. Aluminum, an extremely light and rigid material, is used in the tweeter assembly to maximize efficiency.

Spun-Copper Thermoformed Crystalline Polymer Woofers

Leveraging technology from Klipsch’s highly acclaimed Reference Premiere series, the 4" TCP woofers are designed with a steeper cone angle for a smoother response, greater precision, and improved transparency.

High-Quality Cabinet Design & Appearance

The speakers feature hidden fasteners, edge-to-edge horn, and low-profile magnetic grilles, giving them a sleek, modern appearance. MDF cabinets with scratch-resistant wood grain finish seamlessly integrate into home décor.

Technical Specifications:

• 1-inch LTS (Linear Travel Suspension) aluminum diaphragm tweeter with Kapton suspension, equipped with a vented rear enclosure and next-generation Tractrix Horn 90° x 90°, featuring a wider horn that extends to the edges of the cabinet, providing a wider soundstage and more precise imaging.
• 4-inch (10 cm) TCP (Thermoformed Crystalline Polymer) woofers with spun copper membrane, designed for a more linear and transparent response.
• Reflex port with exit on the rear panel.
• Nominal impedance: 8 ohms.
• Sensitivity: 91 dB (2.83 V / 1 m).
• Frequency response: 71 Hz - 21 kHz (+/- 3 dB).
• Crossover frequency: 1770 Hz.
• Supported power: 200 W peak / 50 W RMS.
• Cork pad under the base for superior stability on the surface.
• Magnetic grille with hidden attachments under the front panel finish.
• Black finish with wood grain and scratch-resistant satin paint on the front panel.
• Dimensions (W x H x D): 146 x 298 x 216 mm.
• Weight: 3.2 kg.
