DUAL CS 418

Emphasis on high component precision is a feature of the entire range of Dual products. This is the case for the entry model CS 418, which uses the same platform as the higher models in the product range.
 The Ortofon 2M Red pickup and a switchable MM-phonopreamplifier are an integral part of this ready to run package.
The CS 418 is not attractive just because it is excellent value for money, but it also offers a superb and compelling balanced sound experience and a 5 year warranty for long term ownership.

Details:
Plinth: Solid MDF
Folded MDF construction with a black vinyl veneer
Elastomer vibration absorber integrated inside the feet
Removable dust cover

Platter: Aluminium Die-cast
Precise aluminium die-cast
Heavy rubber mat for resonance damping
Solid platterbearing with a hardened steel spindle in a brass bushing

Tonearm: Straight, statically balanced
Solid aluminum construction with ball-bearings
Damped tonearmlift
Adjustable trackingforce and antiskating

Drive: DC- Motor / Belt
Low vibration DC-Servo-Motor
Rubber mountings for vibration decoupling
Precision cut belt for lower wow & flutter



Technical Data:
Motor
Drive: Belt
Speed settings: 33/45/78
Wow & Flutter: < ±0,1 % (DIN WTD)

Tonearm
Auto-Start/-Stop-Function: ???
Bearing: Ball-bearing
Effective length: 221,5 mm
Offset Angle: 25,6°
Overhang: 19 mm
Type: statically balanced
Stylus Pressure Range: 0 g bis 4 g
Cartridge Weight Range 5 g bis 9 g
Factory installed pick up: Ortofon 2M Red

Platter
Material: Aluminium die-cast
Mat: Rubber 2,5 mm
Bearing: Hardened steel spindle Brass bushing
Diameter: 305 mm
Weight (incl. Mat): 850 g

Plinth:
Material: MDF, folded
Surface finish: Vinyl veneer / Black
Feet: Ø 62 mm / Elastomer
Connection: RCA socket
Connection to Phono Input: ???
Connection to Line Input: ???
Digital Output: ???
Dimension, closed dustcover: 435 x 367 x 145 mm
Dimension, open dustcover: D: 415 mm / H: 400 mm
Weight: 5,8 kg
Power plug AC / DC: External power supply
