LAiV HARMONY DAC R2R

The discounted price change with the finish

The DAC Harmony by Laiv combines an elegant and minimalist design with discrete and balanced R2R digital-to-analog conversion technology. Designed to ensure faithful sound reproduction, it supports sampling rates up to DSD256 and PCM 768kHz. The internal CRYSTEK CCHD-957 FEMTO clock ensures exceptionally low phase noise, further enhancing sound quality. Its modular design offers flexibility, easy upgrades, and maintenance, making it a versatile and practical choice.

At the heart of the DAC Harmony is its R2R resistor ladder, built with high-precision components featuring a tolerance of 0.05%, ensuring accurate and detailed sound reproduction. The power supply relies on high-end components such as Audio Note Kaisei and Rubycon ZLH capacitors, eliminating electrical interference and contributing to exceptional audio quality. The 3.83-inch OLED display provides all the necessary information, while the intuitive controls and customizable remote further enhance the user experience. The DAC Harmony also includes an I2S input for integration with an external clock.

Technical specifications:

• Product Type: R2R DAC
• Inputs:
  • 1x USB-B
  • 1x Optical
  • 1x Coaxial
  • 1x I2S
• Outputs:
  • 1x Stereo XLR
  • 1x Stereo RCA
• Processor: Intel Altera Cyclone FPGA
• Supported Frequencies:
  • USB: up to PCM 768kHz, DSD256
  • Optical: up to PCM 192kHz
  • Coaxial: up to PCM 192kHz
  • I2S: up to PCM 768kHz, DSD256
• Display: 3.83-inch OLED
• Internal Clock: CRYSTEK CCHD-957
• Frequency Response: 20Hz-20kHz ± 0.25dB
• Total Harmonic Distortion (THD): 0.0035%
• Crosstalk: 110 dB
• Signal-to-Noise Ratio (SNR): 123 dB
• Dynamic Range: 110 dB
• Output Impedance:
  • XLR: 1200 Ω
  • RCA: 600 Ω

• Dimensions: 75 x 250 x 255 mm
• Weight: 4.3 kg
