KLIPSCH RP-5000F II

Reference Premiere II Series.

A new, larger 90° x 90° hybrid silicone composite Tractrix® horn enables incredibly efficient transfer of high-frequency waves into the listening area for crisper, clearer sound. The phase plug and compression-molded silicone face ensure smooth, consistent frequency response.

The 1" Linear Travel Suspension (LTS) tweeter minimizes distortion, enhancing performance with greater detail. LTS tweeters are a distinctive feature of the Reference Premiere series, making it a core component of some of the best speakers in the world. The vented tweeter housing reduces standing waves that create unwanted harmonics, improving detail and clarity in high-frequency reproduction.

The 5.25" Cerametallic™ woofers have been updated to deliver flawless sound reproduction with minimal distortion and maximum efficiency. The redesigned woofer provides the power, detail, and emotion expected from a Klipsch Reference Premiere speaker. The Tractrix port design, with Tractrix geometry, allows for the fastest and most efficient air transfer from the cabinet, reducing port noise for punchier, cleaner bass frequencies.

The separate bi-wiring/bi-amping input terminals separate high and low-frequency current into different cables, reducing distortion for clearer midrange. Bi-amping allows for further performance optimization with separate outboard amplifiers for high- and low-frequency drivers.

Upgrading to immersive Dolby Atmos sound with the RP-500SA speakers is incredibly easy, thanks to hidden connections on the back of the speakers. These refined connections reduce wire visibility while holding them in place for better wire management.

Technical Specifications:

• 2-way floorstanding bass reflex speaker
• Cabinet with advanced design and construction, featuring additional reinforcements and internal volume division, inert, colorless, and effective at eliminating resonance, vibrations, and standing waves
• 1" LTS (Linear Travel Suspension) titanium diaphragm tweeter with a vented housing and proprietary next-generation Hybrid Cross-Section Expanded Tractrix Horn 90° x 90°
• Computer-modeled phase plug and compression-molded silicone outer surface, with a wider horn extending to the sides of the cabinet, enhancing the soundstage extension and image accuracy
• 2 x 5.25" (13.3 cm) Cerametallic™ copper-colored woofers with flat dust caps, redesigned for reduced distortion, improved speed, articulation, and power handling
• Dual Tractrix Ports in separate chambers with rear panel exits
• New connector set for optional Atmos-enabled channel connections, hidden behind a removable plate and located at the top of the rear panel
• Nominal impedance: 8 ohms
• Sensitivity: 95 dB (2.83 V / 1 m)
• Frequency response: 40 Hz - 25 kHz (+/- 3 dB)
• Crossover frequency: 1900 Hz
• Power handling: 400 watts peak / 100 watts RMS
• Dual set of terminals for bi-wiring and bi-amping with audiophile-grade wiring
• Die-cast aluminum decoupling feet
• Magnetic grille with hidden attachments under the finish
• Elegant copper trims around the speakers
• Scratch-resistant satin black front panel
• Dimensions (W x H x D): 207 x 917 x 375 mm
• Weight: 17.5 kg
