KLIPSCH R-605F

Next-gen Reference Series Dolby Atmos. Floorstanding speaker, 2-way bass reflex with an additional certified 2-way Dolby Atmos enabled pneumatic suspension channel embedded in the top panel. Advanced cabinet design and construction, with internal bracing, inert and free of coloration.

The updated horn design, with enlarged external dimensions, delivers greater power and excitement in both music and movies. A larger horn means better control over directionality across a wider frequency range, resulting in a more precise soundstage.

Aluminum tweeter with Linear Travel Suspension (LTS)

A distinctive feature of Klipsch speakers, the exclusive 1" LTS tweeter with Kapton suspension minimizes distortion, ensuring more detailed performance. Aluminum, an extremely light and rigid material, is used in the tweeter assembly to maximize efficiency.

Thermoformed Crystalline Polymer (TCP) woofer with copper finish

Thanks to the technology from Klipsch's renowned Reference Premiere series, the 4" TCP woofers are designed with a more pronounced cone angle for smoother response, increased precision, and enhanced transparency.

High-quality cabinet design and aesthetics

The speakers feature hidden attachments, an edge-to-edge horn, and low-profile magnetic grills, giving them an elegant and modern look. The MDF cabinets, with scratch-resistant wood grain finishes, blend seamlessly into home décor.

Technical specifications:

• 2 LTS (Linear Travel Suspension) 1" tweeters with aluminum diaphragm and Kapton suspension, featuring a rear-vented housing and next-generation proprietary Tractrix Horn 90° x 90° loading system (for both front and Dolby Atmos enabled channels).

• A wider horn that extends to the edges of the cabinet, capable of reconstructing a wider soundstage and more precise imaging.

• 2 front-facing 6.5" (16.5 cm) woofers + 1 top-facing 5.25" (13.3 cm) woofer for the Dolby Atmos channel, with TCP (Thermoformed Crystalline Polymer) copper filament diaphragm.

• Redesigned to ensure a more linear and transparent response.

• Tractrix Port reflex port with rear panel exit.

• Nominal impedance: 8 ohms.

• Sensitivity: 96 dB (2.83 V / 1 m).

• Frequency response: 38 Hz - 21 kHz (+/- 3 dB).

• Crossover frequency: 1440 Hz.

• Supported power: 400 W peak / 100 W RMS.

Dolby Atmos channel specifications:

• Nominal impedance: 8 ohms.

• Sensitivity and frequency response compliant with Dolby Atmos specifications.

• Supported power: 150 W peak / 75 W RMS.

• Dolby Atmos terminals located next to the main channels.

• Injection-molded decoupling feet.

• Magnetic grill with attachments hidden under the front panel finish.

• Black finish with wood grain and satin anti-scratch front panel coating.

• Dimensions (W x H x D): 240 x 1017 x 463 mm.

• Weight: 22.7 kg.
