GRAHAM CHARTWELL LS3/5A

Optional stands € 1430,00

The LS3/5A model was produced by the BBC's Design Department in response to changes in the performance characteristics of the drivers originally chosen for the LS3/5. This is the most popular model produced by the BBC and is still considered a reference speaker for many audiophiles today.

Graham Audio has faithfully reintroduced the LS3/5A to the market, meticulously adhering to the original BBC specifications, including authentic details such as the perforated metal tweeter grille and the use of felt pads to protect the tweeter. The cabinet is constructed with 12mm thick panels, featuring a sealed enclosure to eliminate unwanted resonances and ensure distortion-free audio reproduction.

This speaker, with its ability to handle continuous power of 25 W, delivers a balanced and precise frequency response, especially in the midrange, and is designed for highly detailed listening.

Technical Specifications:

• Frequency Response: 80 - 20,000 Hz (±3 dB)
• Sensitivity: 83 dB SPL (2.83V, 1m)
• Nominal Impedance: 11Ω
• Maximum Power: 25 W
• High-Frequency Driver: T27 SP1032 19 mm (mylar dome)
• Low-Frequency Driver: B110 SP1003 110 mm (bextrene diaphragm)
• Crossover Frequency: 3,000 Hz
• Enclosure Type: Sealed
• Dimensions (H x W x D): 11.81 x 7.48 x 6.69 inches
• Weight: 11.68 lbs (per speaker)
