GOLD NOTE GIGLIO

Turntable Gold Note Giglio with tonearm B-5.1

The Italian turntable
We believe that every hand made turntable has something special and what we make carries a small part of the Italian heritage, showing our dedication to native traditions, history and to our passion: this is how we craft perfect music sources.
Such passion defines all our turntables and drives us to design with great care and attention every single detail in order to deliver the best audio performance from the most fascinating source of music.
Giglio is one of our best creations and - with Mediterraneo - redefines the traditional design of a turntable through innovative shapes, quality materials and technical solutions to merge tradition and technology.
The particular curves of the base result in extra rigidity and allow Giglio to achieve a superior performance delivering pure sound and details to recreate the musical event. The wooden base is also coupled with a 20mm thick board in polished Acrylic and reinforced with a 3mm stainless steel platform lowering the total frequency resonance.
Enhancing the turntable's ultra-compact structure, combining and refining the technical design with elegant, smooth lines: that's how we created Giglio.
The Walnut curved plinth is in fact coupled with a 3mm stainless steel board then completed with a 20mm thick black polished acrylic board that integrates the electronic system.
The new polished pulley with its hourglass design allows the belt to spin smoothly reducing even more the Wow&Flutter and the rumble.
Even the platter is designed to minimise vibrations with noiseless functionality and low platter/plinth distance for greater stability.

" a smooth performer, with an effortless style that makes it easy to forget the mechanics of the process and enjoy the music"

The Power Supply of the 12 Volt Swiss Made synchronous motor has been developed to guarantee fantastic audio performances.
Thanks to our proprietary power control generator based on a Quadral-Core micro-controller, Giglio can effectively control vibrations and deliver high torque for the greatest dynamic and resolution.
The Power Supply Unit electronically control the 33rpm and the 45rpm mode and the speed fine adjustment, storing the settings in memory.
Giglio features a 33mm thick platter made of Sustarin and a high precision bearing/spindle design with ultra-strict matching tolerances.
The spindle is made of rectified hardened chromed Steel and the bearing is in tungsten steel, both engineered to obtain great rotational stability and low noise.
The platter in black Sustarin - a special material based on POM plastic polymer, rigid and high dampened - reduces vibrations and improves the stability.

TRIPLE DAMPENED PlINTHS
Giglio is built with a multiple plinth structure based on the main 50mm wooden base made of Italian Walnut hardwood slats.
The base is coupled with a 20mm plinth in polished Acrylic and reinforced with a 3mm thick stainless steel platform to guarantee exceptional stability and rigidity.

QUADRAL-CORE POWER SUPPLY
Giglio features a proprietary best power control generator based on Quadral-Core micro controller enhances an audio converter completely reshape the AC wave to perfectly drive a 12V synchronous motor to virtually cancel vibrations and improve torque power for greatest dynamic and details resolution both.

HIGH PRECISION PLATTER
Giglio features a 33mm thick platter made of Sustarin and a high precision bearing/spindle design with ultra-strict matching tolerances.
The spindle is made of rectified hardened chromed Steel and the 5mm bearing is in tungsten steel, both engineered to obtain great rotational stability and low noise.

EASY SET UP
Ready to play out of the box, the bundle includes a dedicated Gold Note B5.1 tonearm and a custom moulded transparent Dust Cover (easy to remove with our proprietary hinges).

* available also in white or black lacquered on demand

Technical specifications
Dimensions: 425mm W | 200mm H | 360mm D
Weight: 15Kg
Wow & Flutter: 0,1%
Rumble: -78dB
Speed: 33-1/3 and 45 rpm +/-0,1%
Transmission: 70 shore rectified NBR belt
Speed: electronic with fine pitch control
Motor: 12 Volt High Torque synchronous externally powered
Platter: Ultra Dead Design Sustarin® 33mm thick
Platter spindle: special Split-Spindle
Platter bearing: Chromed steel 5mm ball bearing with adjustable brass seat finely Polished bronze case
Acrylic Dust Cover included

POWER
Mains supply: 100/115/230V, 50/60Hz, depending on market destination and not convertible
Power consumption: 20W max

Tonearm B-5.1
B-5.1 is an elegant tone arm designed for efficiency and completely hand made in Italy with great care to achieve maximum precision. Behind its ease of use, a refined engineering is hidden to get the best sonic results.
Inside B-5.1 you'll find four high precision micro ball-bearings manufactured by GRW in Germany and then singularly sealed and packed to preserve their integrity and purity at the best: extreme precision is a crucial factor and it allows B-5.1 to function in ideal noiseless condition to reproduce without effort every musical detail.
B-5.1 effective length of 242mm with 19mm overhang makes it easy to install on any turntable.
The tone arm features a double counterweight system to set up most phono cartridge (up to 15 gram mass) - optionally, other extra weights are available to handle even phono cartridges with higher mass.
Quality materials, like finely machined Aluminium 6000, and italian flair make this tone arm the perfect choice for demanding audiophiles.
The vertical ball-bearings are pivoted through stainless steel bolts manually adjusted, the horizontal movement is driven by two micro ball-bearings directly inserted in the main rectified pivot.
With a 23mm diameter arm shaft, B-5.1 can be secured on every turntable, improving performances and every day pleasure.

Specifications
9" Ball Bearing Tonearm
Total length: 315mm
Total weight: 200g
Effective length: 242mm
Overhang: 19mm
Offset: 24°
Arm wand: Aluminium 6000
Shaft: 23mm
Dynamic effective mass: 10g
VTF: 0.176N (18g)
VTA: adjustable on collar
Lift: hydraulic
Anti skating: wire
Azimuth: adjustable on the headshell
Internal cables: AWG36 Hyper Litz shielded 99,9999% OFC
External cables: 1,5m custom 4 pole DIN/RCA
