ELAC MIRACORD 80

Version with premounted cartridge

The Miracord 80 aims to continue the legacy of ELAC turntables, which began back in 1948, and does so through a range of features that fully express its quality. The plinth, milled from solid wood, is enhanced by anodized aluminum panels that add stability and mass to the system. With an overall weight of 14 kg, the Miracord 80 turntable is designed to offer stable and precise performance.

The platter, weighing a solid 5.6 kg, is one of the distinguishing features of the Miracord 80. Characterized by a complex bearing design, it is driven by a belt-driven DC servo-controlled motor, which, thanks to optical control, ensures exceptional speed stability (+/- 0.33 % @ 3 kHz) and a Wow and Flutter rate lower than < 0.15%. The 10-inch tonearm, made of carbon fiber, is designed to minimize tracking errors due to its advanced geometry. Additionally, it can be equipped with an MM D96 cartridge, specially developed by Clearaudio for ELAC.

The Miracord 80 is a perfect example of ELAC's long-standing tradition in the world of vinyl, focusing on a complete and immersive audio experience. The elegant design, combining milled solid wood and anodized aluminum panels, gives the turntable a refined and distinctive appearance. An optional cover can be added to protect the mechanism from dust impurities.

With its heavy platter, the turntable provides the necessary inertia for smooth and precise movement, while the PID-controlled DC motor ensures impeccable speed stability. The combination of the motor and the 10-inch carbon fiber tonearm reduces tracking errors, improving reproduction quality and stereo separation.

The Miracord 80 is the ultimate choice for vinyl enthusiasts, a high-quality product that combines precious materials like wood, aluminum, and carbon with a design that perfectly blends tradition and technological innovation. This turntable is not just a means to listen to music but a true declaration of love for analog and sound quality, offering a superior listening experience.

Technical Specifications:

• Tonearm type: genuine carbon fiber
• Effective tonearm length: approximately 10"
• Speed accuracy: +/- 0.33% at 3 kHz
• Wow and flutter: < 0.15%
• Crosstalk damping: > 25 decibels
• Connectivity: gold-plated RCA jack, ground terminal
• Speed: 33.3 and 45 RPM
• Platter weight/size: 5.6 kg / > 298 mm diameter, 30 mm height
• Drive: platter speed optically controlled, PID-controlled DC motor, belt drive
• Power consumption: 1.5 W (less than 0.5 W in standby)
• Maximum dimensions: 470 x 374 x 148 mm (L x W x H)
• Weight: 14 kg
