HANA SH

The Hana SH combines high output with high resolution, courtesy of its special coil design and Shibata stylus. Compatible with standard MM phono stages, a high-output MC provides dynamics, drive, and excellent stereo imaging.
With over 50 years experience in cartridge design and manufacture, Excel Sound builds many of the most highly regarded high-output MC cartridges.

Stylus     Shibata
Cantilever     Aluminum
Output Level     2mv/1kHz
Output Balance     <1.5dB/1 KHz
Vertical Tracking Force     2g
Trackability     70 µm/2g
Channel Separation     28dB/1kHz
Frequency Response     15-32,000Hz
Impedance     130?/1kHz
Suggested Load Impedance     47k?
Cartridge Weight     5g
Body Color     Black
Warranty     2 years
