VAN DEN HUL THE WAVE HYBRID
Signal cable 1 m
Code: 28994743
All our products are covered by Italian warranty.
The WAVE celebrates its 25 years of GreenCare; van den Hul???s own green program that warrants that from the first till the last day of existence, each cable will not harm the environment at all. This has been one of our important design criteria in the past quarter of a century.
The WAVE is a coaxial, triple shielded interconnect designed to simply outperform its price class with superior qualities.
Being not just any other "coax cable", The WAVE's finely balanced design and materials inside comprise more than 25 years of experience and material knowledge, resulting into impeccable transmission quality.
Another strong aspect of The WAVE is that its high natural bandwidth and excellent noise rejection properties make it applicable in a wide variation of audio as well as 75 ? video interconnect situations.
The WAVE is ideal for use as an audio interconnect in wiring your home theatre setup, in going from CD or DVD player to amplifier or in any other hi-fi line level wiring application.
Due to the fact that it's also a highly accurate 75 ? cable, The WAVE is equally perfect in AV applications like antenna/cable TV, video, surround and S/PDIF digital audio connections.
Specifications:
Cable Type: Coaxial
Conductor Material: Dense Silver coated high purity Matched Crystal OFC
Design Purpose/Application Area(s): Multi-purpose AV interconnect
Eff. Conductor ??/Eq. AWG No./Strands: Core: 0.64 mm_. / AWG 19 / Core: 1; Screen: 96 + Al foil + 112
External Diameter / Dimensions: 7.3 mm
Resistance 20 °C / 68 °F: Core: 2.7 Ohm/100 m.; Screen: 0.55 Ohm/100 m
Capacitance: 57 pF/m
Characteristic Impedance: 75 Ohm
Insulation / Dielectric Strength / Test Voltage: Core: PE foam; Jacket: HULLIFLEX ® 4 / 300 Vrms min
Connector Types Suitable: Special version of our RCA type C - 7.3; Our BNC type BNC - 7.0; Television style coaxial plugs
Standard Sales Units / Lengths: Stereo pair packed with RCA (unbalanced) connectors in 0.8 & 1.0m
Six lead packed sets for AV applications with RCA (unbalanced) connectors in 0.6, 0.8 & 1.0m. lengths
Jacket Colours Available: Olive green
Remarks: Connectors need to be factory mounted
