LEHMANN AUDIO BLACK CUBE STATEMENT
Phono Preamplifier
Code: 14192692
All our products are covered by Italian warranty.
The Black Cube Statement is the entry-level model in our Black Cube series. With the usual high-grade quality of workmanship and the sophisticated circuit design this phono preamp is hardly inferior to its large siblings - and saves your budget!
The Black Cube Statement will impress you - no matter if you are a newbie to the high-end sector or a returner. Your favourite LPs shine in new splendor and new acquisitions really come into their own now. That way collecting records is truly great fun again!
With an excellent price-performance ratio the term "entry-level model" is fundamentally redefined. The use of high-quality long-life components from selected manufacturers is self-evident for us so that already the smallest phono preamp of our Black Cube series will bring you the captivating magic of analogue reproduction. Needless to say that all components we use have been designed with longevity and dependability in mind.
A comfortable all-rounder
Of course, the Black Cube Statement can handle all common cartridges on the market, from high-output MM to MC. Practice-oriented MC impedances are directly selectable. In addition each channel features a slot for the solder-free plug-in of a custom impedance. On request we will gladly enclose resistors with your order for matching your system to this phono stage - free of charge, naturally.
Due to its modest dimensions the Black Cube Statement can be placed very close to the turntable which will minimise possible losses resulting from cable lengths. By the way, Lehmannaudio is always dedicated to detail, not only with the component selection, but during the entire manufacturing process: for instance, the enclosure of the audio section is made of a non-magnetic material (aluminium) and the cover lid is mechanically dampened.
Specifications
Sensitivity for output level 775 mV/0 dB (with activated high gain jumper)
Gain 1 kHz
Maximum input level
Signal to noise ratio (RMS unweighted) MM: 7.4 mV/1 kHz; MC: 0.74 mV/1 kHz
MM: 41 dB; MC: 61 dB
MM: 58 mV; MC: 5.6 mV
MM: 78 dB; MC: 57 dB
Gain 31 dB, 41 dB, 51 dB, 61 dB
Channel separation > 85 dB at 10 kHz
Input impedance 47 kohms, 1 kohm, 100 ohms
1 x custom load
Output impedance < 100 ohms
Input capacitance 100 pF
Channel mismatch typ. 0.5 dB
Bass filter 50 Hz, 6 dB/oct.
Power consumption app. 1 VA
Outer dimensions W x D x H 103 mm x 108 mm x 45 mm
Weight 0.28 kg netto
