MCINTOSH MA5300

The MA5300 Integrated Amplifier is proof that great sound can come in a compact package. It is our smallest solid-state integrated amplifier in terms of both power output and physical size, making it an ideal choice for smaller spaces or for someone just starting to build a home audio system. It is a direct-coupled amplifier that delivers 100 watts per channel into 8-ohm speakers or 160 watts per channel into 4-ohm speakers. The new dual-scale blue watt meters provide an accurate reading of power output for both 4-ohm and 8-ohm impedances.

The MA5300 offers 12 inputs, including 6 analog inputs (4 unbalanced, 1 balanced, and 1 Moving Magnet input for turntables) and 6 digital inputs (2 coaxial, 2 optical, 1 USB, and 1 proprietary MCT for use with our MCT series SACD/CD transports). All digital inputs are housed in our DA1 Digital Audio Module, which can be replaced with future modules as new digital audio technologies are developed. The DA1 features an 8-channel, 32-bit Digital-to-Analog Converter (DAC) used in Quad Balanced mode and supports up to DSD256 and DXD 384kHz for high-resolution audio playback. All inputs can be easily renamed to simplify system control and configuration.

The MA5300 includes McIntosh Monogrammed Heatsinks™, which are connected to advanced high-current output transistors that eliminate warm-up time, allowing you to enjoy the full sonic capabilities of the MA5300 from the moment you turn it on. Powerful new control microprocessors have been used to improve overall system operation, along with some of the latest audio-grade circuit components to deliver the best possible sound. Bass and treble tone controls have been added to help you fine-tune your music to your personal preferences.

The MA5300 is one of many McIntosh products to receive the Roon Tested designation from Roon Labs. As a Roon Tested partner, McIntosh has provided equipment to Roon for testing with various operating systems and computers, sharing information about its design and capabilities.

Completing the MA5300 are time-tested McIntosh technologies, including Power Guard®, Sentry Monitor™, Home Theater PassThru, High Drive headphone amplifier with Headphone Crossfeed Director (HXD®), and gold-plated speaker binding posts. The classic McIntosh aesthetic with blue watt meters, a black glass front panel with aluminum end caps, control knobs, and an illuminated logo completes the MA5300.

Technical Specifications:

• FTC Power Output: 100 W
• Power Output per Channel: 100 W into 8 ohms, 160 W into 4 ohms
• Number of Channels: 2
• Rated Power Band: 20Hz to 20kHz
• Total Harmonic Distortion: 0.005%
• Dynamic Headroom: 1.8dB
• Frequency Response +0, -0.5dB: 20Hz to 20kHz
• Frequency Response, +0, -3dB: 10Hz to 100kHz
• Phono Sensitivity (Moving Coil): N/A
• Phono Sensitivity (Moving Magnet): 2.5mV
• High-Level Sensitivity (Balanced / Unbalanced): 0.5V / 0.25V
• Sensitivity (Power Amp Input): 1V
• Signal-to-Noise Ratio (Moving Coil): N/A
• Signal-to-Noise Ratio (Moving Magnet): 82dB
• Signal-to-Noise Ratio (High-Level): 95dB
• Signal-to-Noise Ratio (Power Amp Input): 110dB
• Input Impedance (Balanced / Unbalanced): 20K/20K
• Damping Factor: 8 ohms: >200, 4 ohms: >100
• Maximum Output (Balanced / Unbalanced): 8V Unbalanced
• Unit Dimensions (W x H x D): 44.45 cm x 15.2 cm x 47.6 cm
• Unit Weight: 17.2 kg
