ORTOFON 2M BLACK LVB 250 PREMOUNTED

The 2M Black LVB 250 upgrades the great build of the 2M Black with a boron cantilever and our very own Nano Tube suspension system. The result is a sound so precise and so detailed that you feel like you have let the artist into your house and have them playing right in your living room.

The 2M Black is mounted on our classic SH-4 headshell.

Accuracy level
The 2M Black is an amazing cartridge and, by many, considered the ultimate in moving magnet. So, why would we attempt to create something even better? Because perfection runs in our blood.
The 2M Black LVB 250 upgrades the great build of the 2M Black, and the result is a sound so precise and so detailed that you feel like you have let the artist into your house and have them playing right in your living room.

Stylus
The 2M Black LVB 250 upgrades the great build of the 2M Black with a Nude Shibata diamond on a boron cantilever. The use of an extremely stiff and lightweight Boron cantilever adds remarkable transparency, speed, and responsiveness.
The Nude Shibata stylus’ slim, highly polished profile allows an exceedingly wide contact area to the groove walls and ensures notably detailed reproduction throughout the spectrum, including even the highest frequencies.

Multi Wall Carbon Nano Tubes (MWCNT)
To attain an optimal interaction between compliance and damping, a new rubber compound for the suspension system has been developed. The new rubber compound formula is based on the Multi Wall Carbon Nano Tubes' (MWCNT) highly efficient nano filler. The new MWCNT-based compound offers desirable mechanical properties, which ensure better damping and improve the overall performance of the cartridge.

Specifications
Channel balance at 1 kHz 1 dB
Output voltage at 1 kHz, 5cm/sec 5 mV
Channel seperation at 1 kHz 27 dB
Channel seperation at 15 kHz 15 dB
Frequency response 20 Hz - 20 kHz + 2 / - 1 dB
Tracking ability at 315Hz at recommended tracking force 80 µm
Compliance, dynamic, lateral 22 µm/mN
Stylus type Nude Shibata
Stylus tip radius r/R 6/50 µm
Tracking force range 1.5-1.7 g (15-17 mN)
Tracking force, recommended 1.6 g (16 mN)
Tracking angle 20°
Internal impedance, DC resistance 1.2 kOhm
Cartridge colour Black/Black
Cartridge weight 7.2 g
Premounted cartridge weight 16.7 g
Reccomended load resistance 47 kOhm
Internal inductance 630 mH
Recommended load capacitance 150-300 pF
