AUDIO TECHNICA AT33 EV

The new half-inch standard mount .3 x .7 mil elliptical AT33EV cartridge features a tapered duralumin cantilever. Dual Moving Coil cartridge design increases channel separation and extends the frequency response range delivering extraordinary audio quality. Internally constructed with neodymium magnet for enhanced magnetic energy and PCOCC wire for pure audio transmission.



Specifications
Frequency Response: 15-50,000 Hz
Channel Separation: 30 dB (1 kHz)
Vertical Tracking Force: 1.8-2.2 grams (2.0 grams standard)
Recommended Load Impedance: 100 Ω (with head amplifier connected)
Output: 0.3 (mV at 1 kHz, 3.54 cm/sec)
Channel Balance: 0.5 dB (1 kHz)
Stylus Shape: 0.3 x 0.7 mil nude elliptical
Cantilever: Duralumin tapered pipe
Mount: Half-inch
